Best-selling Center Pivot Irrigation System RainStar

55 customer reviews

An efficient electric center pivot irrigation system delivers precision water distribution for agriculture, manufacturing, and retail, featuring remote monitoring, corrosion-resistant construction (hot-dip galvanized steel, 14.9-24" tires), PLC-controlled motors, customizable lengths (41–61.3m), and comprehensive 2-year system warranty plus 1-year core parts warranty."

  • Description
  • Technical Specifications
  • Manufacturer Capabilities

Efficient Irrigation Solutions
This electric center pivot irrigation system delivers precision water distribution for agriculture, manufacturing, and retail applications. Equipped with a remote monitoring system, users can control and manage operations from anywhere.

Durability & Stability
Constructed with high-grade metals and hot-dip galvanized coatings, the system ensures longevity and corrosion resistance. 14.9-24-inch irrigation tires provide stable and smooth movement across diverse terrains.

Advanced Technology
Powered by PLC-controlled motors and core components from Linsay Technology, the system offers precise water allocation. It includes a 2-year warranty on the entire system and a 1-year warranty on core parts.

Customizable Options
Available in lengths of 41m, 48m, 54.5m, and 61.3m, the system can be tailored to specific irrigation needs. A mechanical test report and guarantee video inspection are provided.

Comprehensive After-sales Support
Our team offers global engineering services, on-site installation, commissioning, training, video technical support, and online assistance to ensure seamless operation and maintenance.

Best-selling Center Pivot Irrigation System


Center Pivot Irrigation System Allocation Standard

Main pipe diameter

6-5/8''(168mm*3.2mm,high frequency welded steel pipe

Standard span

6-5/8''(168mm)*54.5m(8 pipes)

King-sized span

6-5/8''(168mm)*61.3(9 pipes)

Overhang

5-9/16''(141mm)

King-sized overhang

4''(101mm)

Pipe length

22feet/one (6.7m)

Main pipe Flange thickness

10mm, Flange and pipe adopt double welded technology

Working voltage

460--380V/50--60HZ

Power supply mode

Diesel generator and the local power company provide

Tire type

14.9-24 irrigation tire

Motor power

0.75~1.5 horse power

Motor speed reducer

output speed of electric transmission gearbox:28~86RPM

Span body tower structure

Adopt "V" model tower

All the equipment with

The pressure of Nelson pressure governor:15PSI   (20PSI)(10PSI)

Main cable

4*4mm²+6*1.0mm²(resisting ultra violet and aging

The end has

LED working status instruction light

Irrigation intake

1 water inlet in center point,quick pipe joint connected structure

Irrigation intake caliber

8inches,the spot water supply pipe is more than 6 inches

Irrigation intake pressure

0.20--0.35mpa

Standard irrigation truss height from the ground

3.2m

Sprayer spacing

2.2--4m (the quantity:2-3sprayer/water pipes

After complete machine steel component was welded, it adopts hot galvanizing

ZONAL PIVOT IRRIGATION

The spans rotate less than 360 degree and therefore maximize the irrigated surface area when there is an obstacle (farm building, tree,pylon etc.) situated in the middle of the Field, or where the shape of the Field does not allow full rotation.An automatic reverse system allows continuous operation whilst the security system ensures that the spans stop at the end of the irrigated.
